Work has begun on the LS-688/VRC loudspeakers and the RAFTs! Well, mostly just the speakers right now.


On the top half there will be 4 speakers; on the bottom 2 RAFTs and 2 speakers. I'm still contemplating whether to add the wing nuts and bolts as separate pieces molded on the containing raft or to model them onto the part. Both ways have their advantages and disadvantages.

New update to the speakers:


There's also another option for the nut/bolt assembly that I forgot about: I could draw in the mounting bracket and leave them at that. That would result in a stronger mold in that area.
HeavyArty
Visit this Community
Florida, United States
Joined: May 16, 2002
KitMaker: 16,801 posts
Armorama: 13,048 posts
Posted: Thursday, April 14, 2016 - 06:14 AM UTC
Speakers look good. I would add the wing nuts so they are part of the speaker, however you have to do that. Can't wait to see them in person. Keep up the great work.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Thursday, April 14, 2016 - 12:40 PM UTC
I've finished the speaker. I made it so that there's 2 options. First includes 3 speakers with a shallow hole in the top to insert a bolt with a wingnut. The second includes 3 speakers with a small slot on the top to be able to accept a mounting bracket (and now in hindsight I forgot to add a bolt and wingnut to that). I've finished the conversion of the set from thick wafer to raft so hopefully it should cut a little bit off the price. I'm not sure if it will be easier to cut the pieces off or not. To do will require some work as the parts are no longer attached to individual connections.
See here:


View of the speakers and close up of raft sprue:


As you can see, shown are also the two options: the bolts and wingnuts and the mounting bracket. I will continue on this later today and hopefully it will be finished soon.
HeavyArty
Visit this Community
Florida, United States
Joined: May 16, 2002
KitMaker: 16,801 posts
Armorama: 13,048 posts
Posted: Thursday, April 14, 2016 - 04:36 PM UTC
Looking good.
amoz02t
#192
Visit this Community
Kentucky, United States
Joined: November 25, 2009
KitMaker: 1,257 posts
Armorama: 1,209 posts
Posted: Thursday, April 14, 2016 - 10:44 PM UTC

Quoted Text

I've finished the speaker. I made it so that there's 2 options. First includes 3 speakers with a shallow hole in the top to insert a bolt with a wingnut. The second includes 3 speakers with a small slot on the top to be able to accept a mounting bracket (and now in hindsight I forgot to add a bolt and wingnut to that). I've finished the conversion of the set from thick wafer to raft so hopefully it should cut a little bit off the price. I'm not sure if it will be easier to cut the pieces off or not. To do will require some work as the parts are no longer attached to individual connections.
See here:


View of the speakers and close up of raft sprue:


As you can see, shown are also the two options: the bolts and wingnuts and the mounting bracket. I will continue on this later today and hopefully it will be finished soon.



This does look good! Please keep in mind how brittle the SHAPEWAY's material is for the part connection points. Would just hate to see it shatter at the wrong location and chip away some of your great work here. Many thanks for this offering. Following closely.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 01:07 AM UTC
Thats also why I'd advise using a saw or a thin dremel grinder instead of sprue snips. Keep the bag it comes in. Cut off the entire section of the raft that you want and then go in with a saw from underneath the part. That's just one way I thought of at the moment. Granted it does leave many loose parts but unfortunately I'm not sure of any other way as the part sits now. And too much work has been done to revert back.

Also, as per a request I went back and redid the model of the LVTP-7A1 hatches to decrease the base area in an attempt to lower the cost of the part. Unfortunately because of the way Shapeways calculates the cost it doesn't bring any major savings - more along the lines of a few cents. But it's something.
GeraldOwens
Visit this Community
Florida, United States
Joined: March 30, 2006
KitMaker: 3,522 posts
Armorama: 3,483 posts
Posted: Friday, April 15, 2016 - 01:15 AM UTC

Quoted Text

Hey everybody. I've been doing a bit of 3D design work for a time now and I have a shop set up at Shapeways here: Mike's Model Shop. I'm looking for more projects and I'd like to know what you guys here would like to see. If I think I can do it, I'll try it. I don't have any armor stuff up yet but I hope to expand that.

I am looking for people to do some reviews on the products (eventually). If you would like to do a review, you have to buy the product yourself as I just don't have the money to buy review products for everyone. If you want to, contact me and I can remove the markup for a short period of time so you could buy the product at the lowest price (Shapeways' base price, I won't be getting anything from that). I will do that for the first 5 review purchases per product.

That said, I am not a professional with this program, Autodesk Inventor, and I do this as a side hobby. There are some things I just can't do, some due to limitations of the program and some just because I don't have the experience but if I think I can do it, I will try it.

So anyone have any suggestions?


How about a set of stowage box handles and periscope and headlight guards for the venerable Italeri M47 Patton?
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 02:21 AM UTC
I don't think I'll be able to do headlight guards yet. For something as complex as that I like to have an example or complete drawings in my hands which I don't have. And I wouldn't know where to find drawings of the guards.

I'll attempt the stowage box handles. I'll try to make them as economical as possible.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 03:18 AM UTC
Actually, surprisingly, the prices on the hatches set have dropped quite a bit. I think by about $10 each. So I'm actually pleasantly surprised. Does anyone have any more information on the RAFT component like the component number? For example the loudspeaker is LS-688/VRC but I can't find anything for the RAFT. I'm having a difficult time trying to figure out the dimensions for it.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 05:51 AM UTC
I've updated the basic radio set. This includes only the 1 MCS, 4 regular FFCS, 2 MOS, 2 RIT and now 4 speakers. I hope it will be a cheaper option for anyone who do not need the Data/Telephone components or RRUs or who just want a cheaper option.

And Gino, I have a speaker set up on the shop currently hidden from public.
HeavyArty
Visit this Community
Florida, United States
Joined: May 16, 2002
KitMaker: 16,801 posts
Armorama: 13,048 posts
Posted: Friday, April 15, 2016 - 07:11 AM UTC
Sounds good. How do I get to the speaker set?
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 07:21 AM UTC
Here: https://www.shapeways.com/product/GRQSNMBA5/1-35-an-vic-3-v-ls-688-vrc-loudspeakers?key=e18a0b5fbc3b4ea7fc35488784ddf9bf&optionId=59695614
hazzardm
Visit this Community
England - South West, United Kingdom
Joined: May 13, 2010
KitMaker: 27 posts
Armorama: 26 posts
Posted: Friday, April 15, 2016 - 02:29 PM UTC
Hi Mike, justs tumbled across this discussion. Seems everyone is into radio kit so what about a 1960-1970 radio set such as an RT66-GRC (it would be set applicable for vietnam vehicles (mutts, M113 etc)and IDF stuff up to lebanon (jeeps, half tracks etc).

One set of say 2 radios, + 1 amp plus a couple of speakers would be really useful.

I have scratchbuilt 3 sets now and would really like not to have do any more with that horrible crinkly surface finish

I can supply info if necessary as I have set sitting in my 1/1 IDF jeep

what are your thoughts

Mark Hazzard
amoz02t
#192
Visit this Community
Kentucky, United States
Joined: November 25, 2009
KitMaker: 1,257 posts
Armorama: 1,209 posts
Posted: Friday, April 15, 2016 - 07:40 PM UTC



Got my order in as well. Thanks for putting this out there!
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Friday, April 15, 2016 - 11:27 PM UTC
I've set the speaker set to public and raised the price by a little as the only person who had bought a radio set without speakers has bought them. I've also lowered the price of the tie downs/grab handles set.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Saturday, April 16, 2016 - 11:06 AM UTC

Quoted Text

How about a set of stowage box handles and periscope and headlight guards for the venerable Italeri M47 Patton?



So you have wished it, so it shall be:



This was actually a bit more complicated and much more time consuming than I had previously thought. Mostly because the program stopped responding often and crashed occasionally.

You can find it here: http://shpws.me/M4BQ


Quoted Text

Hi Mike, justs tumbled across this discussion. Seems everyone is into radio kit so what about a 1960-1970 radio set such as an RT66-GRC (it would be set applicable for vietnam vehicles (mutts, M113 etc)and IDF stuff up to lebanon (jeeps, half tracks etc).

One set of say 2 radios, + 1 amp plus a couple of speakers would be really useful.

I have scratchbuilt 3 sets now and would really like not to have do any more with that horrible crinkly surface finish

I can supply info if necessary as I have set sitting in my 1/1 IDF jeep

what are your thoughts

Mark Hazzard



Sure. I've found some general dimensions of the exterior but if you could provide of the specifics that'd be great and would make for a quicker model time.

ArtyG37B
Visit this Community
British Columbia, Canada
Joined: August 13, 2009
KitMaker: 398 posts
Armorama: 395 posts
Posted: Thursday, April 21, 2016 - 04:57 AM UTC
Hi Michael,
How about the loaders hatch for a M3A2 Bradley?

MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Sunday, April 24, 2016 - 12:13 PM UTC
Get me a picture and some measurements and I'll attempt it. I can't find much specifics with my limited Google-fu.

Also, I now present a time that many of you have been waiting for... I have finally finished the AN/VIC-3(V) model. I completed the RAFTs early this morning and now here is a picture of the 3D model:


I will be getting the shop product updated now. This will be for the full version of the set.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Monday, April 25, 2016 - 09:23 AM UTC
I'm also now working on a cut out of that sprue with just the rafts included.
spoons
Visit this Community
England - East Anglia, United Kingdom
Joined: January 09, 2008
KitMaker: 527 posts
Armorama: 500 posts
Posted: Monday, April 25, 2016 - 09:21 PM UTC
hows about doing these guys..
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Monday, April 25, 2016 - 09:23 PM UTC
I can't do figures.
MikeyBugs95
Visit this Community
New York, United States
Joined: May 27, 2013
KitMaker: 2,196 posts
Armorama: 1,698 posts
Posted: Thursday, April 28, 2016 - 10:53 AM UTC
I've started work on some M113 ramp pulleys. Should be finished soon.
yeahwiggie
Visit this Community
Dalarnas, Sweden
Joined: March 24, 2006
KitMaker: 1,877 posts
Armorama: 1,144 posts
Posted: Thursday, April 28, 2016 - 10:58 AM UTC
Need any more ideas?
How about 1/24 scale accessories and weapons?
Stuff like jerrycans, backpacks or some standard issue military gear?
Rifles, shotguns, pistols.... stuff like that?
